Fast 30kw 380V CCS Rapid Charger Portable DC Chademo Charger

  • 1
  • 2

Brand Name : ANS

Model Number : ANS-DL-PC

Certification : TUV

Place of Origin : china

MOQ : 1

Price : USD

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000PCS/month

Delivery Time : 20-30days

Packaging Details : 15.7*15*3.15(in)

Brand : ANS

product name : 30kW DC Portable EV charger

Application : DC portable charger

Material : TPU

Protection level : IP43

Warranty : 2years

Certifications : CE

Operating temperature : -30℃-+50℃

Contact Now

Electway Fast 30kw 380V portable dc chademo ccs rapid charger car Portable EV charger







Product Description



Model
30KW
AC Input
Input Rating
380Vac±15%
AC Input Connection
3P + N +PE, Wye connection
Max. Input Current
60A
Frequency
50 /60 Hz
Power Factor
>0.99@full load
Efficiency
95%
DC Out put
Output Voltage Range
200-750Vdc
Max, Output Power
30KW
Max. Output Current
100A
User Interface
TFT-LCD Touch Panel
No
Push Buttons
No
Interface
USB
Packing
Dimension
570×190×350mm
Weight
50KG
Environmental
Operating Temperature
-40~85℃,25℃(TYPE)
Humidity
5%-90% RH, non-condens,ng
Altitude
2000m
IP Level
IP43
Mechanical
Cable Length
5M (CHAdeMO) , 5M (CCS), 5M(GB/T) Customized acceptable
Regulation
EN61851-1
Regulation
Certification
CE , ROHS
Charging protocol
CHAdeMO 2.0 / DIN 70121/ISD1S118/IEC618Sl-23,IEC618Sl-24



Product Detail



Fast 30kw 380V CCS Rapid Charger Portable DC Chademo Charger



30kw portable CCS Standard DC Fast EV Charger

◆ The 30KW portable charger produced by our company, with input voltage of 380Vac±15% voice navigation, easy to use, rated output power of 30KW, Max current with 100A. This product has the corresponding rainproof cover, which is specially customized for this type of charger. If necessary, you can contact with the customer service.
◆By monitoring module, power module, lightning protection unit, intelligent and friendly interface, etc.
◆High performance charging module, super wide charging range, high efficiency.
◆ 4.3 inch display screen, the display screen will prompt the operation steps, intuitive and simple, beautiful and generous.
◆ Can also be customized production according to vehicle BMS parameters.
◆High efficiency:≥95%
